HIKVISION DS-2TD6537T-50H4LX/W User Manual

Thermal Network Positioning System·Quick Start Guide
5
3 Appearance Description
3.1 Positioning System Appearance
Refer to the following figures for thermal positioning system overview.
Figure 3-1 Thermal Positioning System Overview
Table 3-1 Description of Thermal Positioning System
No.
Description
1
Optical
2
IR Light
3
Power Cable
4
Thermal
3.2 Cable Descriptions
The cable interfaces of positioning system are shown in Figure 3-2. The cables of power
supply, alarm inputs, alarm outputs, etc. are distinguished by different colors. Please
refer to the labels attached on the cables for identification.
