Figure 1-3 Front Panel of DS-7200HQHI-F/N
Table 1-2 Description of Front Panel
Turns green when the power switch on the rear panel
is turned on.
Flickers red when data is being read from or written to
HDD.
Flickers green when network connection is functioning
properly.
Universal Serial Bus (USB) ports for additional devices
such as USB mouse and USB Hard Disk Drive (HDD).
Front Panel 4:
Figure 1-4 Front Panel of DS-7200HUHI-F/N and DS-7600HUHI-F/N
