Digital Video Recorder User Manual
254
Figure 17-3 General Settings Interface (for Independent VGA and HDMI Output)
Step 3 Configure the following settings:
Language: The default language used is English.
Output Standard: Select the output standard to be PAL or NTSC.
VGA/HDMI Resolution: Select the output resolution, which must be the same with the
resolution of the VGA/HDMI display.
For DS-7300/8100/9000HUHI-F/N series, VGA/HDMI1 Resolution and HDMI2 Resolution
can be configured separately. Up to 1920 × 1080/60 Hz resolution is supported for
VGA/HDMI1 output and up to 4K (3840 × 2160)/30 Hz resolution is supported for HDMI2
output.
For DS-7608/7616HUHI-F/N and DS-7300/8100HQHI-F/N series DVR, the HDMI and VGA
interfaces can be configured to be simultaneous or independent (Refer to Chapter 17.4
Configuring More Settings for reference). If you have configured HDMI/VGA simultaneous
output, you can set the VGA/HDMI Resolution. If you have configured independent HDMI
and VGA output, you can set the VGA Resolution and HDMI Resolution independently. Up
to 1920 × 1080/60 Hz resolution is supported for VGA output and up to 4K (3840 × 2160)/30
Hz resolution is supported for HDMI output.
Time Zone: Select the time zone.
Date Format: Select the date format.
System Date: Select the system date.
System Time: Select the system time.
Mouse Pointer Speed: Set the speed of mouse pointer; 4 levels are configurable.
Enable Wizard: Enable/disable the Wizard when the device starts up.
Enable Password: Enable/disable the use of the login password.
