Digital Video Recorder User Manual
43
Rear Panel 2:
Figure 1-12 Rear Panel of DS-7200HGHI-F (/N)
Rear Panel 3:
Figure 1-13 Rear Panel of DS-7200HGHI-E
Table 1-11 Description of Rear Panel
BNC interface for HDTVI and analog video input.
HDMI video output connector.
DB15 connector for VGA output. Display local video
output and menu.
Universal Serial Bus (USB) port for additional devices.
