HIKVISION DS-7104HGHI-F1 Quick Start Guide

Digital Video Recorder Quick Start Guide
38

The POS overlay function is only supported by DS-7300/8100HQHI-F/N and
DS-7300/8100/9000HUHI-F/N series DVR. When the POS is enabled in playback, the POS
information will be overlaid on the video.

For DS-7200HUHI-F/S series DVR, you can click to show the VCA information in the
smart playback. Then the configured line or quadrilateral in VCA configuration and target
frame(s) will be shown on the playback interface. Click to hide the VCA information.
Figure 3-26 Show VCA Information in Smart Playback
Step 4 (Optional) Select the channel(s) to execute simultaneous playback of multiple channels.

HIKVISION DS-7104HGHI-F1 Specifications

General

Video Compression	H.264
Video Input	4 channels
Audio Input	1 channel
Audio Output	1 channel
HDD Interface	1 SATA interface
HDD Capacity	Up to 6TB
USB Interface	2 × USB 2.0
Power Supply	12 VDC
Operating Temperature	-10 °C to +55 °C
Operating Humidity	10% to 90%
Video Output	1 VGA, 1 HDMI
Network Interface	1 RJ45 10M/100M Ethernet interface
