18.1.2 DS-7200HGHI-E1
Model DS-7204HGHI-E1 DS-7208HGHI-E1 DS-7216HGHI-E1
Video/
Audio input
Video
compression
H.264
Analog and
Turbo HD video
input
4-ch 8-ch 16-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron
connection
Supported
camera types
720p25, 720p30, CVBS
IP video input
1-ch 2-ch
Up to 720p
resolution
Up to 1080p resolution
Audio
compression
G.711u
Audio
input/Two-way
audio input
1-ch, RCA (2.0 Vp-p, 1 KΩ)
Video/
Audio output
HDMI/VGA
output
1920 × 1080/60Hz,1280 × 1024/60Hz, 1280 × 720/60Hz, 1024
× 768/60Hz
Encoding
resolution
720p/VGA/WD1/4CIF/CIF
Frame rate
Main stream: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
Sub-stream:
2CIF@6fps;
CIF/QVGA/QCIF@
25fps (P)/30fps (N)
Sub-stream:
4CIF/2CIF@6fps;
CIF/QVGA/QCIF@25fps (P)/30fps (N)
Video bit rate 32 Kbps to 4 Mbps
Audio output 1-ch, RCA (Linear, 1 KΩ)
Audio bit rate 64 Kbps
Dual-stream Support
Stream type Video, Video & Audio
Synchronous
4-ch 8-ch 16-ch

HIKVISION DS-7104HQHI-F1/N Specifications

General

Voltage	12 V
Product color	White
Rack capacity	1U
Audio output channels	1.0 channels
Video compression formats	H.264, H.264+
BNC input ports	1
Video input channels	4 channels
USB 2.0 ports quantity	2
Ethernet LAN	Yes
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Power consumption (typical)	8 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	800 g
Dimensions (WxDxH)	200 x 200 x 45 mm
