18.1.10 DS-7100HGHI-F1/N
Model
DS-7104HGHI-F1
/N
DS-7108HGHI-F1
/N
DS-7116HGHI-F1
/N
Video/
Audio input
Video
compression
H.264+/H.264
Analog video
input
4-ch 8-ch 16-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
Turbo HD input 720p25, 720p30
AHD input 720p25, 720p30
HDCVI input 720p25, 720p30
CVBS input Support
Audio
compression
G.711u
Audio
input/Two-way
audio input
1-ch, RCA (2.0 Vp-p, 1 KΩ)
Video/
Audio output
HDMI/VGA
output
1-ch, 1920 × 1080/60Hz,1280 × 1024/60Hz, 1280 × 720/60Hz,
1024 × 768/60Hz
Encoding
resolution
720p/WD1/4CIF/VGA/CIF
Frame rate
Main stream:
For 720p stream access:
720p/WD1/4CIF/VGA@12fps;
CIF@25fps (P)/30fps (N)
For SD stream access:
WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
Sub-stream:
CIF/QVGA/QCIF@25fps (P)/30fps (N)
Video bit rate 32 Kbps to 4 Mbps
Audio output 1-ch, RCA (Linear, 1 KΩ)
Audio bit rate 64 Kbps
