Digital Video Recorder User Manual
268
Each two video channels are grouped in sequence, e.g., CH01 and CH02, CH03 and CH04...; and
each two channels in the same group must be connected with the same type of video source
CIF/QVGA/QCIF@
25fps (P)/30fps (N)
CIF/QVGA/QCIF@25fps (P)/30fps (N)
Video bit rate
32 Kbps to 4 Mbps
Audio output
1-ch, RCA (Linear, 1 KΩ)
Audio bit rate
64 Kbps
Dual-stream
Support
Stream type
Video, Video & Audio
Synchronous
playback
4-ch
8-ch
16-ch
Network
management
Remote
connections
32
128
Network
protocols
TCP/IP, PPPoE, DHCP, Cloud P2P, DNS, DDNS, NTP, SADP,
SMTP, NFS, iSCSI, UPnP™, HTTPS
Hard disk
SATA
1 SATA interface
Capacity
Up to 6 TB capacity for each disk
External
interface
Network
interface
1, 10M/100Mbps self-adaptive Ethernet interface
USB interface
2 × USB2.0
General
Power supply
12 VDC
Consumption
(without HDD)
≤ 8 W
≤ 12 W
≤ 20 W
Working
temperature
-10 ºC to +55ºC (14 ºF to 131ºF)
Working
humidity
10% to 90%
Dimensions
(W × D × H)
260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch)
Weight
(without HDD)
≤ 1 kg (2.2 lb)
≤ 1.2 kg (2.6 lb)

HIKVISION DS-7108HGHI-F1 Specifications

General

Voltage	12 V
Certification	CE
Product color	White
Channels quantity	8 channels
Maximum frame rate	30 fps
Audio output channels	2.0 channels
Audio formats supported	G.711
Multi-display supported	Yes
Network connection type	RJ-45
Maximum video resolution	1920 x 1080 pixels
Video compression formats	H.264
Playback resolutions supported	1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Video in	BNC
Video out	HDMI, VGA
Audio input	1x RCA
BNC input ports	8
USB 2.0 ports quantity	2
Number of users	128 user(s)
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Power requirements	DC
Power consumption (typical)	12 W

Weight and Dimensions

Weight	800 g
Dimensions (WxDxH)	200 x 200 x 45 mm
