Digital Video Recorder User Manual
78
Start Auto-switch: the screen is auto switched to the next one. And you must set the dwell
time for each screen on the configuration menu before enabling the auto-switch.
Menu>Configuration>Live View>Dwell Time.
Start Recording: normal record and motion detection record are supported.
Output Mode: select the output mode to Standard, Bright, Gentle or Vivid.
Playback: play back the recorded videos for current day.
Aux/Main Monitor: the DVR checks the connection of the output interfaces to define the
main and auxiliary output interfaces. When the aux output is enabled, the main output cannot
do any operation, and you can do some basic operation on the live view mode for the Aux
output.
For DS-7300/8100/9000HUHI-F/N series, there are two HDMI interfaces. HDMI1 and VGA
interfaces share simultaneous output. The priority level for the main and aux output is HDMI2>
VGA/HDMI1. The CVBS output only serves as the aux output or live view output. The priority
relationship is shown as Table 3-2.
Table 3-2 Priorities of Outputs for DS-7300/8100/9000HUHI-F/N Series
For Live View
Output Only
For DS-7608/7616HUHI-F/N and DS-7300/8100HQHI-F/N series DVR, the HDMI and VGA interfaces
can be configured to be simultaneous or independent.
For DS-7608/7616HUHI-F/N and DS-7300/8100HQHI-F/N series DVR with CVBS output, if the HDMI
and VGA interfaces are configured to be independent, the priority level of the main and aux
output is HDMI > VGA. The CVBS output only serves as the aux output or live view output. The
priority relationship is shown as Table 3-3. If the HDMI and VGA interfaces are configured to be
simultaneous, the VGA/HDMI output is the main output. The CVBS output is the aux output. The
priority relationship is shown as Table 3-4.
Table 3-3 Priorities of Independent Outputs for DS-7608/7616HUHI-F/N and DS-7300/8100HQHI-F/N
Series
For Live View Output Only
To Next Page
