HIKVISION DS-7108HQHI-K1 User Manual

Digital Video Recorder User Manual
23
Figure 1-4 Remote Control
The keys on the remote control closely resemble the ones found on the front panel. Refer to Table
1-4, they include:
Table 1-4 Description of the IR Remote Control Buttons
No.
Name
Description
1
POWER
Power on/off the device.
Power on/off the device by pressing and holding the
button for 5 seconds.
2
MENU Button
Press the button to return to the main menu (after
successful login).
Press and hold the button for 5 seconds will turn off
audible key beep.
In PTZ Control mode, the MENU button will start wiper
(if applicable).
In Playback mode, it is used to show/hide the control

HIKVISION DS-7108HQHI-K1 Specifications

General

BNC input ports	1
Video input channels	8 channels
USB 2.0 ports quantity	2
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Power consumption (typical)	12 W
Voltage	12 V
Product color	White
Rack capacity	1U
Audio output channels	1.0 channels
Video compression formats	H.264, H.264+, H.265, H.265+
Ethernet LAN	Yes
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	1000 g
Dimensions (WxDxH)	200 x 200 x 45 mm
