HIKVISION DS-7108NI-K1/W/M - Playback

Table 3-1 Description of Live View Icons
Item
Description
Item
Description
Alarm (video loss, tampering,
motion detection, VCA or
sensor alarm).
Alarm and Record.
Record (manual record,
continuous record, motion
detection, VCA or alarm
triggered record).
Event/Exception (event and
exception information,
appears at the lower-left
corner of the screen).
3.8 Playback
The recorded video files and pictures on HDD can be played back. Refer to the user manual for
details of each playback mode.
Steps
1. Go to Menu → Playback.
2. Select the channel(s) in the channel list for playback.
3. Double click a date on the calendar.
4. Optional: Use the toolbar at the bottom to control the playing progress.
5. Optional: Select the channel(s) to execute simultaneous playback of multiple channels.
Figure 3-8 Playback
