HIKVISION DS-7200-ST Series Quick Operation Guide

DS-7200-ST Series DVR Quick Operation Guide
28
DS-7200HFI-ST:
Model
DS-7204HFI-ST
DS-7208HFI-ST
DS-7216HFI-ST
Video/Audio
input
Video compression H.264
Analog video input
4-ch
8-ch
16-ch
Video input interface BNC connector (1.0 Vp-p, 75 Ω); PAL / NTSC adaptive
Audio compression
G.71 1
Audio input 4-ch, RCA connector (2.0 Vp-p, 1 kΩ)
Voice talk input 1-ch, RCA (2.0 Vp-p, 1 kΩ)
VGA output 1-ch, resolution: 1280 × 1024 / 60 Hz, 1024 × 768 / 60 Hz
CVBS output
2-ch, BNC connector (1.0 Vp-p, 75 Ω); Resolution: PAL: 704 ×
576, NTSC: 704 × 480
Audio output 1-ch, RCA connector (Linear, 1 kΩ)
Video/Audio
output
Recording resolution 4CIF / 2CIF / CIF
Frame rate
Main stream:
4CIF / 2CIF / CIF@25 fps (P) / 30 fps (N)
Sub stream:
CIF@6 fps, QCIF@25 fps (P) / 30 fps (N)
Video bit rate 32 kbps ~ 2048 kbps, or user-defined (Max. 3072 kbps)
Stream type Video/ Video & Audio
Audio bit rate
64 kbps
Dual stream Support
Synchronous playback 4-ch 8-ch 16-ch
Hard disk
Type 1 SATA interface 2 SATA interfaces
2 SATA interfaces
Capacity Up to 2TB capacity for each interface
External
interface
Network interface 1, RJ45 10 M / 100 M adaptive Ethernet interface
Serial interface
1 RS-485 full-duplex interface, 1 RS-232 interface
USB interface 2, USB 2.0
Alarm in 4 8 16
Alarm out 1 4 4
Others
Power supply 12 VDC
Consumption
≤10 W (without
hard disk or
DVD-R/W)
≤15
W (without
hard disk or
DVD-R/W)
≤20
W (without
hard disk or
DVD-R/W)
Working temperature
-10 ºC ~ +55 ºC
Working humidity 10% ~ 90%
Chassis
Stand-
alone 1U
chassis
19-inch
rack-mounted
1U chassis
19-inch
rack-mounted
1U chassis
Dimensions
(W× D× H)
315 × 230 × 45 mm 445 × 290 × 45 mm 445 × 290 × 45 mm
Weight
≤
2 kg (without
hard disk or
DVD-R/W)
≤ 4
kg (without
hard disk or
DVD-R/W)
≤ 4
kg (without
hard disk or
DVD-R/W)
