DS-7200-ST Series DVR Quick Operation Guide
29
DS-7200HFI-ST/SE:
Model
DS-7204HFI-ST/SE
DS-7208HFI-ST/SE
DS-7216HFI-ST/SE
Video/Audio
input
Video compression
H.264
Analog video input
4-ch
8-ch
16-ch
Video interface
BNC connector (1.0 Vp-p, 75 Ω); PAL / NTSC adaptive
Audio compression
G.711
Audio input
1-ch,RCA connector (2.0 Vp-p, 1 kΩ)
Voice talk input
1-ch, RCA (2.0 Vp-p, 1 kΩ)
(Using AUDIO IN)
VGA output
1-ch, resolution: 1280 × 1024 / 60 Hz, 1024 × 768 / 60 Hz
CVBS output
1-ch, BNC connector (1.0 Vp-p, 75 Ω);
Resolution: PAL: 704 × 576, NTSC: 704 × 480
Audio output
1-ch, RCA connector (Linear, 1 kΩ)
Video/Audio
output
Recording
resolution
4CIF/2CIF/CIF
Frame rate
Main stream:
4CIF / 2CIF / CIF@25 fps (P) / 30 fps (N)
Sub stream:
CIF@6 fps, QCIF@25 fps (P) / 30 fps (N)
Video bit rate
32 kbps ~ 2048 kbps, or user-defined (Max. 3072 kbps)
Stream type
Video/ Video & Audio
Audio bit rate
64 kbps
Dual stream
Support
Synchronous
playback
4-ch 8-ch 16-ch
Hard disk
Type
1 SATA interface 2 SATA interfaces 2 SATA interfaces
Capacity
Up to 2TB capacity for each interface
External
interface
Network interface
1, RJ45 10 M / 100 M adaptive Ethernet interface
Serial interface
1 RS-485 full-duplex interface
USB interface
2, USB 2.0
Others
Power supply
12 VDC
Consumption
≤10 W (without hard
disk or DVD-R/W)
≤15 W (without hard
disk or DVD-R/W)
≤20 W (without hard
disk or DVD-R/W)
Working
temperature
-10 ºC ~ +55 ºC
Working humidity
10% ~ 90%
Chassis
Stand-alone 1U chassis
19-inch rack-mounted
1U chassis
19-inch rack-mounted
1U chassis
Dimensions
(W × D × H)
315 × 230 × 45 mm 445 × 290 × 45 mm 445 × 290 × 45 mm
Weight
≤2 kg (without hard disk
or DVD-R/W)
≤4 kg (w
ithout hard
disk or DVD-R/W)
≤4 k
g (without hard
disk or DVD-R/W)
