HIKVISION DS-7204HUHI-K1 User Manual

Digital Video Recorder User Manual
228
Model
DS-7204HUHI-K2
DS-7208HUHI-K2
DS-7216HUHI-K2
USB interface
2 × USB 2.0
Front panel: 1 × USB 2.0
Rear panel: 1 × USB 3.0
Serial
interface
RS-485 (half-duplex)
Alarm in/out
4/1
8/4
16/4
General
Power supply
12 VDC
Consumption
(without
HDD)
≤ 10 W
≤ 20 W
≤ 25 W
Working
temperature
-10 ºC to +55 ºC (+14 ºF to +131 ºF)
Working
humidity
10% to 90%
Dimensions
(W × D × H)
380 × 320 × 48 mm (15.0 × 12.6 × 1.9 inch)
Weight
(without
HDD)
≤ 1.16 kg (2.6 lb)
≤ 1.78 kg (3.9 lb)
≤ 2 kg (4.4 lb)
17.1.6 DS-7200HQHI-K/P
Model
DS-7204HQHI-K1
/P
DS-7208HQHI-K2/
P
DS-7216HQHI-K2/
P
Video/Audio
input
Video
compression
H.265+/H.265/H.264+/H.264
Analog video
input
4-ch
8-ch
16-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
HDTVI input
3 MP, 1080p30, 1080p25, 720p60, 720p50, 720p30, 720p25
Note: The 3 MP signal input is only available for channel 1 of
DS-7204HQHI-K1/P, channel 1/2 of DS-7208HQHI-K2/P, and
channel 1/2/3/4 of DS-7216HQHI-K2/P.
AHD input
1080p25, 1080p30, 720p25, 720p30

HIKVISION DS-7204HUHI-K1 Specifications

General

Video Input	4 channels
Video Output	1 HDMI, 1 VGA
Video Bitrate	32 Kbps to 6 Mbps
Audio Bitrate	64 Kbps
Dual Stream	Yes
Stream Type	Video, Video & Audio
Synchronous Playback	4-ch
SATA	1 SATA interface
HDD Capacity	Up to 10 TB capacity for each disk
Network Interface	1, RJ45 10M/100M self-adaptive Ethernet interface
Power Supply	12 VDC
Operating Humidity	10% to 90%
Max Resolution	1080p
Video Compression	H.264+
Audio Output	1-ch RCA (Linear, 1 KΩ)
Two-Way Audio	1-ch, RCA (2.0 Vp-p, 1 KΩ)
HDMI Output	1
VGA Output	1
Recording Resolution	1080p
Playback Resolution	1080p
Network Protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, UPnP™, HTTPS
USB Interface	2 USB 2.0
Operating Temperature	-10 °C to +55 °C
