Digital Video Recorder User Manual
56
 Playback: play back the recorded videos for current day.
 Aux/Main Monitor: the DVR checks the connection of the output interfaces to define the
main and auxiliary output interfaces. When the aux output is enabled, the main output cannot
do any operation, and you can do some basic operation on the live view mode for the Aux
output.
For DVR with CVBS output, the VGA/HDMI output is the main output, and the CVBS output is the
aux output. The priority relationship is shown as Table 3-2.
Table 3-2 Priorities of Outputs
S.N
HDMI
VGA
CVBS
Main output
Auxiliary output
1
√ or ×
√ or ×
√ or ×
VGA/HDMI
CVBS
√ means the interface is in use, × means the interface is out of use or the connection is invalid. And
the HDMI, VGA and CVBS can be used at the same time.
3.2.1 Using the Mouse in Live View
You can refer to Table 3-3 for the description of mouse operation in live view mode.
Table 3-3 Mouse Operation in Live View
Name
Description
Menu
Enter the main menu of the system by right clicking the
mouse.
Single Screen
Switch to the single full screen by choosing channel number
from the drop-down list.
Multi-Screen
Adjust the screen layout by selecting from the drop-down list.
Previous
Screen
Switch to the previous screen.
Next Screen
Switch to the next screen.
Start/Stop
Auto-Switch
Enable/disable the auto-switch of the screens.
The dwell time of the live view configuration must be set before using
Start Auto-Switch.

HIKVISION DS-7204HUHI-K1 Specifications

General

Video Input	4 channels
Video Output	1 HDMI, 1 VGA
Video Bitrate	32 Kbps to 6 Mbps
Audio Bitrate	64 Kbps
Dual Stream	Yes
Stream Type	Video, Video & Audio
Synchronous Playback	4-ch
SATA	1 SATA interface
HDD Capacity	Up to 10 TB capacity for each disk
Network Interface	1, RJ45 10M/100M self-adaptive Ethernet interface
Power Supply	12 VDC
Operating Humidity	10% to 90%
Max Resolution	1080p
Video Compression	H.264+
Audio Output	1-ch RCA (Linear, 1 KΩ)
Two-Way Audio	1-ch, RCA (2.0 Vp-p, 1 KΩ)
HDMI Output	1
VGA Output	1
Recording Resolution	1080p
Playback Resolution	1080p
Network Protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, UPnP™, HTTPS
USB Interface	2 USB 2.0
Operating Temperature	-10 °C to +55 °C
