Digital Video Recorder User Manual
272
Each two video channels are grouped in sequence, e.g., CH01 and CH02, CH03 and CH04...; and
each two channels in the same group must be connected with the same type of video source
(Turbo HD or CVBS). The above information is for reference only. Please refer to the specific
configuration of the device.
SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
Hard disk
SATA 2 SATA interfaces
Capacity Up to 6 TB capacity for each disk
External
interface
Network interface 1, 10M/100M self-adaptive Ethernet interface
USB interface 2 × USB 2.0
General
Power supply 12 VDC
Consumption
(without HDD)
≤ 12 W ≤ 20 W
Working
temperature
-10 ºC to +55 ºC (14 ºF to 131 ºF)
Working humidity 10% to 90%
Dimensions
(W × D × H)
380 × 320 × 48 mm (14.9 × 12.6 × 1.9 inch)
Weight
(without HDD)
≤ 2 kg (4.4 lb)
