Digital Video Recorder User Manual
124
Step 5 Select Linkage Action tab to set up alarm response actions of the alarm input (Refer to
Chapter 8.7 Setting Alarm Response Actions).
Repeat the above steps to set up arming schedule of other days of a week. You can also use
Copy button to copy an arming schedule to other days.
Step 6 (Optional) Select PTZ Linking tab and set PTZ linkage of the alarm input.
Set PTZ linking parameters and click the OK button to complete the settings of the alarm
input.
Check whether the PTZ or speed dome supports PTZ linkage.
One alarm input can trigger presets, patrol or pattern of more than one channel. But presets,
patrols and patterns are exclusive.
Figure 8-7 Set PTZ Linking of Alarm Input
Step 7 If you want to set handling action of another alarm input, repeat the above steps or just
copy the above settings to it.
Figure 8-8 Copy Settings of Alarm Input
