Digital Video Recorder User Manual
21
Name
Function Description
POWER
Power on/off switch.
JOG SHUTTLE Control
Moves the active selection up and down in a menu.
Cycles through different channels in live view mode.
Jumps 30s forward/backward in video files in the
playback mode.
Controls the movement of the PTZ camera in PTZ
control mode.
Moves the active selection up and down in a menu.
USB Interface
Universal Serial Bus (USB) ports for additional
devices such as USB mouse and USB Hard Disk Drive
(HDD).
IR Receiver
Receiver for IR remote control.
Front Panel 3:
Figure 1-3 Front Panel of Other Models

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7208HQHI-K2/P and is the answer not in the manual?

HIKVISION DS-7208HQHI-K2/P Specifications

General IconGeneral
HDD interfaceSerial ATA
Maximum HDD capacity6000 GB
Number of HDDs supported2
Power consumption (typical)60 W
Voltage12 V
Product colorBlack
Audio output channels1.0 channels
Video compression formatsH.264, H.264+, H.265, H.265+
Analog signal format systemNTSC, PAL
BNC input ports1
Video input channels8 channels
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LANYes
Ethernet interface typeFast Ethernet
Supported network protocolsTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
Weight and Dimensions IconWeight and Dimensions
Weight17480 g
Dimensions (WxDxH)380 x 320 x 48 mm
