HIKVISION DS-7208HVI-S & 7216HVI-S User‟s Manual
10
• Other:
• Supports front panel, mouse, IR control.
• Supports multi-level user management, each user can have individual DVR access rights.
• Powerful DVR log, including operation, alarm and exception log.
Product Application Diagram
Internet
PC
PC
Router
VGA Monitor
Speaker
Alarm I/O
Cameras&Speed Dome
Microphone
USB Device
Remote Control
USB Mouse
Figure 3. Product Application Diagram
Operating Your DVR
There are numerous ways to navigate and operate your DVR. You may use the Front Panel Controls, the included IR
(Infra-Red) Remote, a Mouse and the Soft Keyboard.
Using the Front Panel Controls
Your DVR comes with built-in front panel controls, as shown in Figure 4.
