Table 14 Specifications for DS-7224/7232HWI-SH
Model
DS-7224HWI-SH DS-7232HWI-SH
Video/Audio
input
Video compression H.264
Video input 24-ch 32-ch
Video input interface BNC (1.0 Vp-p, 75 Ω), PAL /NTSC self-adaptive
Audio compression G.711u
Audio input 4-ch, RCA (2.0 Vp-p, 1 kΩ)
Two-way audio input 1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input)
Video/Audio
output
HDMI/VGA output
1-ch, resolution:
1080P: 1920×1080P/60 Hz, SXGA: 1280×1024/60 Hz, 720P,
1280×720/60 Hz, XGA: 1024×768/60 Hz
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
Encoding resolution WD1/ 4CIF / 2CIF / CIF / QCIF
Frame rate 25 fps (P) / 30 fps (N)
Video bit rate 32 Kbps ~ 3072 Kbps, or user defined (Max. 3072 Kbps)
Audio output 1-ch, RCA (Linear, 1 kΩ)
Audio bit rate 64 Kbps
Dual-stream
Support;
Sub-stream: CIF / QCIF
Stream type Video, Video & Audio
Synchronous playback 16-ch
Hard disk
SATA 2 SATA interface
Capacity Up to 4TB capacity for each disk
External
interface
Network interface 1, RJ45 10M /100M /1000M Ethernet interface
Serial interface 1 RS-485 interface, half-duplex
USB interface 2, USB 2.0
Alarm in 4
Alarm out 1
General
Power supply 12 VDC
Consumption
(without hard disk or
DVD-R/W)
≤ 25 W
Working temperature -10 ºC ~+55 ºC
Working humidity 10% ~ 90%
Chassis 19-inch rack-mounted 1U chassis
Dimensions
(W × D × H)
445 × 290 × 45 mm
Weight (without hard
disk or DVD-R/W)
≤ 4 kg

HIKVISION DS-7208HWI-SH Specifications

General

Product color	Black
USB connectivity	Yes
Channels quantity	8 channels
Video capturing speed	30 fps
Total storage capacity	8000 GB
Video compression formats	H.264
Analog signal format system	NTSC, PAL
Playback resolutions supported	1920x1080, 1280x1024, 1280x720, 1024x768
Display resolution	960 x 576 pixels
BNC input ports	8
BNC output ports	1
USB 2.0 ports quantity	2
Ethernet interface type	Fast Ethernet
Supported network protocols	NTP, SMTP, NFS, UPnP, iSCSI
HDD interface	Serial ATA
Maximum HDD capacity	4000 GB
Power requirements	12 VDC
Power consumption (typical)	15 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Dimensions (WxDxH)	445 x 290 x 45 mm
