Quick Operation Guide of DS-7200-SH/SV/SL and DS-7300/8100-SH Series DVR
13
Specifications
Table 9 Specifications for DS-7204/7208/7216HFI-SH
Model
DS-7204HFI-SH DS-7208HFI-SH DS-7216HFI-SH
Video/Audio
input
Video compression H.264
Analog video input 4-ch 8-ch 16-ch
IP video input
1-ch 2-ch 2-ch
Up to 720P resolution Up to 1080P resolution
Video input interface BNC (1.0 Vp-p, 75 Ω), PAL/NTSC self-adaptive
Audio compression G.711u
Audio input 1-ch, RCA (2.0 Vp-p, 1 kΩ)
Two-way audio input 1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input)
Video/Audio
output
HDMI/VGA output
1-ch, resolution:
1080P: 1920×1080/60Hz, SXGA: 1280×1024/60Hz,
720P: 1280×720/60Hz, XGA: 1024×768/60Hz
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
Encoding resolution 4CIF / 2CIF / CIF / QCIF
Frame rate 25 fps (P) / 30 fps (N)
Video bit rate 32 Kbps ~ 3072 Kbps, or user defined (Max. 3072 Kbps)
Audio output 1-ch, RCA (Linear, 1 kΩ)
Audio bit rate 64 Kbps
Dual-stream Support; Sub-stream: CIF / QCIF @ 25 fps (P) / 30 fps (N)
Stream type Video, Video & Audio
Synchronous
playback
4-ch 8-ch 16-ch
Hard disk
SATA 1 SATA interface 2 SATA interfaces 2 SATA interfaces
Capacity Up to 4TB capacity
External
interface
Network interface 1, RJ45 10M / 100M Ethernet interface
Serial interface 1 RS-485 interface, half-duplex
USB interface 2, USB 2.0
General
Power supply 12 VDC
Consumption
(without HDD or
DVD-R/W)
≤ 10 W ≤ 15 W ≤ 20 W
Working temperature -10 ºC ~+55 ºC
Working humidity 10% ~ 90%
Chassis Standalone 1U chassis
19-inch
rack-mounted 1U
chassis
19-inch
rack-mounted 1U
chassis
Dimensions
(W × D × H)
315 × 230 × 45 mm 445 × 290 × 45 mm
445 × 290 × 45
mm
Weight
(without HDD or
DVD-R/W)
≤ 2 kg ≤ 4 kg ≤ 4 kg
