Table 22 Specifications for DS-8124/8132HWSI-SH
Model
DS-8124HWSI-SH DS-8132HWSI-SH
Video/Audio input
Video compression H.264
Video input 24-ch 32-ch
Video input interface BNC (1.0 Vp-p, 75 Ω), PAL / NTSC self-adaptive
Audio compression G.711u
Audio input
16-ch,
Audio 1-4: RCA (2.0 Vp-p, 1 kΩ); Audio 5-16: DB26 connector
Two-way audio input 1-ch, RCA (2.0 Vp-p, 1 kΩ)
Video/Audio
output
HDMI/VGA output
1-ch, resolution:
1080P: 1920×1080/60Hz, SXGA: 1280×1024/60Hz,
720P: 1280×720/60Hz, XGA: 1024×768/60Hz
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
Video spot out
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
Encoding resolution WD1 / 4CIF / 2CIF / CIF / QCIF
Frame rate 25 fps (P) / 30 fps (N)
Video bit rate 32 Kbps ~ 3072 Kbps, or user defined (Max. 3072 Kbps)
Audio output 2-ch, RCA (Linear, 1 kΩ)
Audio bit rate 64 Kbps
Dual-stream Support; Sub-stream: CIF / QCIF @ 25 fps (P) / 30 fps (N)
Stream type
Channel 1-16: Video, Video & Audio;
Other channels: Video
Synchronous playback 16-ch
Hard disk
SATA 8 SATA interfaces for 4HDDs + 1 DVD-R/W (default), or 8 HDDs
eSATA 1 eSATA interface
Capacity Up to 4TB capacity
External interface
Network interface 2, RJ45 10M / 100M / 1000M Ethernet interface
Serial interface 1 RS-232, RS-485(full-duplex), Keyboard
USB interface 3 × USB 2.0
Alarm in 16
Alarm out 8
General
Power supply 100~240VAC, 5A, 50~60Hz
Consumption
(without HDD or
DVD-R/W)
≤ 40 W
Working temperature -10 ºC ~+55 ºC
Working humidity 10% ~ 90%
Chassis 19-inch rack-mounted 2U chassis
Dimensions
(W × D × H)
445 × 470 × 95 mm
Weight
(without HDD or
DVD-R/W)
≤ 8 kg

HIKVISION DS-7208HWI-SH Specifications

General

Product color	Black
USB connectivity	Yes
Channels quantity	8 channels
Video capturing speed	30 fps
Total storage capacity	8000 GB
Video compression formats	H.264
Analog signal format system	NTSC, PAL
Playback resolutions supported	1920x1080, 1280x1024, 1280x720, 1024x768
Display resolution	960 x 576 pixels
BNC input ports	8
BNC output ports	1
USB 2.0 ports quantity	2
Ethernet interface type	Fast Ethernet
Supported network protocols	NTP, SMTP, NFS, UPnP, iSCSI
HDD interface	Serial ATA
Maximum HDD capacity	4000 GB
Power requirements	12 VDC
Power consumption (typical)	15 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Dimensions (WxDxH)	445 x 290 x 45 mm
