HIKVISION DS-7216HQHI-F2/N User Manual

Digital Video Recorder User Manual
298
18.1.14 DS-7200HUHI-F1/S
Model DS-7204HUHI-F1/S DS-7208HUHI-F1/S
Video/Audio
input
Video
compression
H.264+/H.264
Analog video
input
4-ch 8-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
Turbo HD
input
5 MP20, 5 MP15, 4 MP25, 4 MP30, 3 MP18, 1080p30, 1080p25,
720p60, 720p50, 720p30, 720p25, NTSC, PAL
AHD input 1080p25, 1080p30, 720p25, 720p30
CVI input 1080p25, 1080p30, 720p60, 720p50, 720p25, 720p30
CVBS input Support
IP video input
2-ch
Up to 4 MP resolution
Audio
compression
G.711u
Audio input 4-ch, RCA (2.0 Vp-p, 1 KΩ)
Video/Audio
output
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 ×
480
HDMI/VGA
output
1-ch, 1920 × 1080/60Hz, 1280
× 1024/60Hz, 1280 ×
720/60Hz, 1024 × 768/60Hz
VGA: 1-ch, 1920 × 1080/60Hz,
1280 × 1024/60Hz, 1280 ×
720/60Hz, 1024 × 768/60Hz
HDMI: 1-ch, 4K (3840 ×
2160)/30Hz, 2K (2560 ×
1440)/60Hz, 1920 × 1080/60Hz,
1280 × 1024/60Hz, 1280 ×
720/60Hz, 1024 × 768/60Hz
Encoding
resolution
5 MP/4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/CIF
Frame rate
Main stream:
5 MP@10fps/4 MP@15fps/3 MP@15fps
1080p/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)

HIKVISION DS-7216HQHI-F2/N Specifications

General

Voltage	12 V
Certification	CE
Product color	White
Rack capacity	1U
Channels quantity	16 channels
Maximum frame rate	30 fps
Audio output channels	2.0 channels
Audio formats supported	G.711
Multi-display supported	Yes
Network connection type	RJ-45
Maximum video resolution	1920 x 1080 pixels
Video compression formats	H.264
Playback resolutions supported	1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Video in	BNC
Video out	HDMI, VGA
Audio input	1x RCA
BNC input ports	16
USB 2.0 ports quantity	2
Number of users	128 user(s)
Ethernet interface type	Gigabit Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Power requirements	DC
Power consumption (max)	30 W

Weight and Dimensions

Weight	2000 g
Dimensions (WxDxH)	380 x 320 x 45 mm
