Network Video Recorder User Manual
43
Server Port
For remote client software access. Ranges from 2000 to 65535. The default value is 8000.
HTTP Port
For remote web browser access. The default value is 80.
Multicast IP
Multicast can be configured to enable live view for cameras that exceed the maximum number
allowed through network. A multicast IP address covers Class-D IP ranging from 224.0.0.0 to
239.255.255.255 and it is recommended to use the IP address ranging from 239.252.0.0 to
239.255.255.255.
When adding a device to the CMS software, the multicast address must be the same as that of
the device.
RTSP Port
RTSP (Real Time Streaming Protocol) is a network control protocol designed for use in
entertainment and communications systems to control streaming media servers. The port is 554
by default.
Output Bandwidth Limit
You can check the checkbox to enable output bandwidth limit.
Output Bandwidth
After enable the output bandwidth limit, input the output bandwidth.
Note
● The output bandwidth limit is used for the remote live view and playback.
● The default output bandwidth is the maximum limit.
