Network Video Recorder User Manual
51
● When the transmission distance reaches 100 to 250 meters, you must use the CAT5e or CAT6
network cable to connect with the PoE interface.
● When the transmission distance reaches 250 to 300 meters, you must use the CAT6 network
cable to connect with the PoE interface.
Figure 6-14 Add PoE Camera
3. Click Apply.
4. Connect PoE cameras to your device PoE interfaces with network cables.
What to do next
The connected PoE camera will be displayed in Configuration → Camera → Camera → IP Channel.
You can click its status to view live image.
Add Non-PoE Network Camera
You can use the PoE channel resource to connect a non-PoE network camera.
Steps
1. Go to Configuration → Camera → Camera → IP Channel.
2. Click of a channel with no linked network camera.
3. Select Adding Method as Manual.
Plug-and-Play
The camera is physically connected to the PoE interface. You can click in the added
device list to edit its parameters.
