Network Video Recorder User Manual
59
4. Select Dwell Time.
Figure 6-22 Edit Alarm Output
5. Set Settings as Input to enable the function.
6. Set the arming schedule. Refer to Configure Arming Schedule for details.
7. Click Apply.
Exception
Exception events can be configured to take the event hint in the live view window and trigger
alarm outputs and linkage actions.
Steps
1. Go to Configuration → Event → Normal Event → Exception.
2. Configure event hint. When the set events occur, you will receive hints in alarm center.
1) Enable Event Hint.
2) Select events to hint. Choose from:
● Click of Event Hint Configuration to select events.
● Click in the upper-right corner of local menu to enter alarm center to select events.
3. Select Exception Type to set its linkage actions.
To Next Page
