Network Video Recorder User Manual
293
18.1.14 DS-7604NI-K1/4P
Model
DS-7604NI-K1/4P
Video/
Audio
input
IP video input
4-ch
Incoming
bandwidth
40 Mbps
Outgoing
bandwidth
80 Mbps
Video/
Audio
output
HDMI/VGA
output
resolution
HDMI:
4K (3840 × 2160)/30Hz, 1920 × 1080/60Hz, 1600 ×
1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz,
1024 × 768/60Hz
VGA:
1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 ×
1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Audio output
1-ch, RCA (Linear, 1 KΩ)
Decoding
Decoding
format
H.265/H.264/H.264+
Recording
resolution
8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/
4CIF/DCIF/2CIF/CIF/QCIF
Synchronous
playback
4-ch
Capability
2-ch @ 4 MP (30fps)
Hard disk
SATA
1 SATA interface for 1HDD
Capacity
Up to 6TB capacity for each disk
Network
managem
ent
Network
protocols
TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP,
SMTP, NFS, iSCSI, UPnP™, HTTPS
External
interface
Two-way audio
1-ch, RCA (2.0 Vp-p, 1kΩ)
Network
interface
1, RJ-45 100 Mbps full-duplex Ethernet interface
USB interface
Front panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0
POE
Interface
4, RJ-45 100 Mbps full-duplex Ethernet interface

HIKVISION DS-7616NI-K2/16P Specifications

General

Input bandwidth	160 Mbit/s
Maximum resolution	3840 x 2160 pixels
Alarm input channels	4
Video input channels	16 channels
Alarm output channels	1
Supported resolutions	3840 × 2160, 2560 × 1440, 1920 × 1080, 1600 × 1200, 1280 × 1024, 1280 × 720, 1024 × 768
Video formats supported	H.264, H.264+, H.265, H.265+, MPEG4
On/off switch	Yes
Product color	Black
Rack capacity	1U
Networking standards	IEEE 802.3af, IEEE 802.3at
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	17
Supported network protocols	TCP/IP, DHCP, HIK Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
Power over Ethernet (PoE) ports quantity	16
HDD capacity	0 GB
HDD interface	Serial ATA
Maximum storage capacity	12 TB
Number of HDDs installed	0
Number of HDDs supported	2
AC input voltage	100 - 240 V
Power consumption (typical)	15 W
Total Power over Ethernet (PoE) budget	200 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Wi-Fi	No

Weight and Dimensions

Depth	315 mm
Width	385 mm
Height	52 mm
Weight	1000 g
