Network Video Recorder User Manual
165
contain the file.
Steps
1. Go to Maintenance Import/Export.
Figure 16-13 Import/Export Configuration File
2. Export or import the device configuration files.
Click Export to export configuration files to the selected local backup device.
To import a configuration file, select the file from the selected backup device and click
Import.
Note
After having finished importing configuration files, the device will reboot automatically.
16.9 Log Management
16.9.1 Log Storage
You can customize the log storage disk and log storage period.
Steps
1. Go to Storage Advanced.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-8632NI-I8/24P and is the answer not in the manual?

HIKVISION DS-8632NI-I8/24P Specifications

General IconGeneral
ModelDS-8632NI-I8/24P
CategoryNetwork Hardware
Video Input Channels32
Max Incoming Bandwidth320 Mbps
Max Outgoing Bandwidth160 Mbps
Video CompressionH.265+/H.265/H.264+/H.264
HDMI Output Resolution4K (3840 × 2160)
VGA Output Resolution1920 × 1080
Two-way AudioYes
Decoding FormatH.265/H.264
Synchronous Playback16 channels
HDD Slots8
SATA8 SATA interfaces
USB Interface2 × USB 2.0, 1 × USB 3.0
Alarm In/Out16/4
PoE Ports24
PoE StandardIEEE 802.3af/at
Operating Temperature-10°C to +55°C
Operating Humidity10% to 90%
Max. Resolution12MP
Audio Input1 channel, RCA
Audio Output1 channel (RCA)
Recording Resolution6MP/5MP/4MP/3MP/1080P/720P
Storage CapacityUp to 10 TB capacity for each HDD
Network Interface1 × 10/100/1000Mbps Ethernet
PoE Interface24 × RJ45 10/100 Mbps
Power Supply100 to 240 VAC, 50 to 60 Hz
Weight (without HDD)≤ 8 kg
Video Output2 × HDMI, 1 × VGA
