HIKVISION DS-9000 Series Quick Start Guide

All-in-One Server Quick Start Guide
8
Figure 1-3 Rear Panel
Table 1-2 Panel Description
No.
Name
No.
Name
1
Server board
9
RS-232 interface
2
Storage board
10
Power supply module
3
HDMI video output
11
Mini SAS interface
4
Audio input/output
12
Reset button
5
USB 3.0 interface
13
RS-485 interface
6
Network interface
14
Keyboard interface
7
eSATA interface
15
Alarm input/output
8
VGA video output
