Network Video Recorder User Manual
54
Figure 6-1 Event Hint Settings
3. Select an exception type.
Figure 6-2 Exceptions Handling
4. Set the linkage actions. Refer to Configure Linkage Actions.
6.1.6 Configure Combined Alarm
Combined alarm combines events with alarm input. The combined alarm will be triggered when it
receives alarms from both alarm input and events. Event types include motion detection, video
tampering detection, and other smart events such as line crossing detection, intrusion detection,
etc.
Before You Start
Ensure the channel has been assigned with event alarm as your desire, and the alarm input has
been configured (refer to Configure Sensor Alarms).
Steps
1. Go to System → Event → Normal Event → Alarm Input.
2. Select an alarm input item from the list and click .
3. Select Settings as Input.
