Network Video Recorder Quick Start Guide
12
2.2.2 DS-96000NI-I24(/H) Series
Purpose:
The following section introduces the HDD installation for the DS-96000NI-I24(/H) series NVR.
Steps:
1. Unlock the front panel with the panel key.
Figure 2. 6 Unlock the Panel
2. To remove the cover from front panel, operate following steps:
1) Slightly pull the cover out of the device along the direction arrow ① and make it a little above the left
handle. The angle between the cover and the front panel must be within 10°.
2) Pull the front panel out of the device along the direction arrow ②.
Handle with care to avoid damage.
Figure 2. 7 Remove the Cover
3. Press the blue button to pop up the handle and hold the handle and pull the hard disk box out of the slot.
Figure 2. 8 Pull out Slot
