Network Video Recorder User Manual
189
Figure 11-5 Behavior Search Results
Step 6 Play the behavior analysis picture related video file.
You can double click on a picture from the list to play its related video file in the view window
on the top right, or select a picture item and click to play it.
You can also click to stop the playing, or click / to play the previous/next file.
Step 7 If you want to export the captured pictures to local storage device, connect the storage
device to the device and click Export All to enter the Export interface.
Click Export to export all pictures to the storage device.
11.3 Plate Search
Purpose:
You can search and view the matched captured vehicle plate picture and related information
according to the plate searching conditions including the start time/end time, country and plate
No..
Step 1 Enter the Plate Search interface.
Menu>VCA Search> Plate Search
Step 2 Select the camera (s) for the plate search.
Step 3 Specify the start time and end time for searching the matched plate pictures.

Table of Contents

Other manuals for HIKVISION DS-9632NI-I16

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-9632NI-I16 and is the answer not in the manual?

HIKVISION DS-9632NI-I16 Specifications

General IconGeneral
Input bandwidth320 Mbit/s
Output bandwidth256 Mbit/s
Maximum resolution3840 x 2160 pixels
Alarm input channels16
Video input channels32 channels
Alarm output channels8
Supported resolutions3840 x 2160, 3840 x 2160, 2560 x 1440, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720, 1024 x 768
Video recording modes1080p, 2160p
Video formats supportedH.264, H.264+, H.265, MPEG4
Audio RCA inputs1
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates10, 100, 1000 Mbit/s
Power over Ethernet (PoE)Yes
Ethernet LAN (RJ-45) ports2
Wi-FiNo
HDD capacity0 GB
HDD interfaceSerial ATA
Maximum storage capacity96 TB
Number of HDDs installed0
Power supply300 W
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (typical)45 W
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
Product colorBlack
Rack capacity3U
Weight and Dimensions IconWeight and Dimensions
Depth496 mm
Width445 mm
Height146 mm
Weight12500 g
