Network Video Recorder User Manual
206
Figure 12-16 Network Settings Interface
Step 3 Click Apply to save the settings.
Step 4 Select the Email tab to enter the Email Settings interface.
Figure 12-17 Email Settings Interface
Step 5 Configure the following Email settings:
Enable Server Authentication (optional): Check the checkbox to enable the server
authentication feature.
User Name: The user name of senders account registered on the SMTP server.
Password: The password of senders account registered on the SMTP server.
SMTP Server: The SMTP Server IP address or host name (e.g., smtp.263xmail.com).
SMTP Port: The SMTP port. The default TCP/IP port used for SMTP is 25.
Enable SSL/TLS (optional): Click the checkbox to enable SSL/TLS if required by the SMTP
server.
Sender: The name of sender.
Senders Address: The Email address of sender.
Select Receivers: Select the receiver. Up to 3 receivers can be configured.

Table of Contents

Other manuals for HIKVISION DS-9632NI-I16

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-9632NI-I16 and is the answer not in the manual?

HIKVISION DS-9632NI-I16 Specifications

General IconGeneral
Input bandwidth320 Mbit/s
Output bandwidth256 Mbit/s
Maximum resolution3840 x 2160 pixels
Alarm input channels16
Video input channels32 channels
Alarm output channels8
Supported resolutions3840 x 2160, 3840 x 2160, 2560 x 1440, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720, 1024 x 768
Video recording modes1080p, 2160p
Video formats supportedH.264, H.264+, H.265, MPEG4
Audio RCA inputs1
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates10, 100, 1000 Mbit/s
Power over Ethernet (PoE)Yes
Ethernet LAN (RJ-45) ports2
Wi-FiNo
HDD capacity0 GB
HDD interfaceSerial ATA
Maximum storage capacity96 TB
Number of HDDs installed0
Power supply300 W
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (typical)45 W
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
Product colorBlack
Rack capacity3U
Weight and Dimensions IconWeight and Dimensions
Depth496 mm
Width445 mm
Height146 mm
Weight12500 g
