HIKVISION DS-9632NI-I16 User Manual

Network Video Recorder User Manual
290
POE
Interface
Interface
8, RJ-45 10/100
Mbps
self-adaptive
Ethernet
interface
16, RJ-45 10/100 Mbps
self-adaptive Ethernet interface
Power
≤ 120 W
≤ 200 W
Supported
standard
IEEE 802.3 af/at
General
Power supply
100 to 240 VAC
Power
≤ 180 W
≤ 280 W
Consumption
(without hard
disk)
≤ 15 W
Working
temperature
-10 to +55° C (14 to 131° F)
Working
humidity
10 to 90 %
Chassis
385 mm chassis
Dimensions
(W × D × H)
385 × 315× 52 mm (15.2" × 12.4" × 2.0")
Weight
(without hard
disk)
≤ 3 kg (6.6 lb)

HIKVISION DS-9632NI-I16 Specifications

General

Input bandwidth	320 Mbit/s
Output bandwidth	256 Mbit/s
Maximum resolution	3840 x 2160 pixels
Alarm input channels	16
Video input channels	32 channels
Alarm output channels	8
Supported resolutions	3840 x 2160, 3840 x 2160, 2560 x 1440, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720, 1024 x 768
Video recording modes	1080p, 2160p
Video formats supported	H.264, H.264+, H.265, MPEG4
Audio RCA inputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Power over Ethernet (PoE)	Yes
Ethernet LAN (RJ-45) ports	2
Wi-Fi	No
HDD capacity	0 GB
HDD interface	Serial ATA
Maximum storage capacity	96 TB
Number of HDDs installed	0
Power supply	300 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	45 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black
Rack capacity	3U

Weight and Dimensions

Depth	496 mm
Width	445 mm
Height	146 mm
Weight	12500 g
