Video Wall Controller • Quick Start Guide
12
Power Supply Requirements
The device supports 100 VAC to 240 VAC@50/60 Hz power supply. To ensure the stable operation
of the device, it is recommended to install UPS for power supply.
Anti-Interference Requirements
The on-site power supply system must have effective measures to prevent grid interference.
Do not use the working ground together with the grounding device or lightning protection
grounding device of power equipment, and keep the two as far away as possible.
Keep away from high-power radio transmitters, radar transmitters, and high-frequency and
high-current equipment.
When necessary, electromagnetic shielding can be used for anti-interference.
Environmental Requirements
The device is a system-level monitoring equipment, which is generally placed in the central
equipment room of the monitoring system at all levels. The selection of the installation site should
comply with the relevant standards of the equipment room construction in the country and region
of use.
The device is a standard rack-mounted equipment. Please pay attention to the following
information during installation and use:
Ensure that the temperature in the rack is from 0 °C to 50 °C.
Ensure that the humidity in the equipment room is between 10% and 90% RH.
Ensure that the rack is strong enough to support the weight of the device and its accessories.
During the installation, avoid the risk caused by uneven mechanical load.
Ensure that there is enough installation space for the video and audio cables. The bending
radius of a cable should not be less than 5 times the cable outer diameter.
Keep the horizontal distance between the video wall controller and other devices above 50
cm for sufficient ventilation.
Install a Board
The device uses the plug-in modular design. You can install service boards to realize different
functions and use the main control board to manage the functions. The following installs a service
board as an example.
Remove some or all baffles from the slots of the device as required.
1) Use a screwdriver to loosen the screws on both sides of a baffle.
2) Pull the baffle out of the slot.
