HIKVISION DS-K1102M Installation Manual

15
Table 4-1 Description of Prompt Sound
Sound
Prompt
Description
One beep
RS
-
485 protocol:
Press
ing
keys
prompt
;
Swiping card prompt; Time out prompt for
pressing keys or swiping card.
Wiegand protocol: Pressing keys prompt;
Swiping card prompt.
Two rapid beeps
The operation of p
ressing
keys or swip
ing
card is valid.
Three slow beeps
The operation of p
ress
ing
keys or swip
ing
card is invalid.
Rapidly
continuous beeps
Alarm of tamper-proof.
Slowly continuous
beeps
The card reader is unencrypted.
Table 4-2 Description of LED Indicator
LED
Indicator Status
Description
Blue and blinking
Card r
ead
er is working normally
.
Solid blue
The operation of pressing keys or swiping
card is valid.
Solid red
The operation of pressing keys or swiping
card is invalid.
Red and blinking
F
or RS
-
485 protocol:
R
egistering failed or
card reader is offline.
Red and
Keeping
rapidly blinking
Available f
or reading file mode of CPU
card: PSAM is not inserted or undetected.
Red
and
keeping
rapidly blinking and
slowly beeps
Failed to get key files of PSAM card; Failed
to detect the PSAM card.

HIKVISION DS-K1102M Specifications

General

Internal	No
Certification	IP64 CE, FCC
Product color	Black
LED indicators	Power, Status
Housing material	Acrylonitrile butadiene styrene (ABS)
Compatible memory cards	-
Input voltage	12 V
Output current	500 mA
Power source type	DC
Power consumption (max)	2 W
Operating temperature (T-T)	-20 - 65 °C
Operating relative humidity (H-H)	10 - 90 %
Interface	RS485 / Wiegand
Supported protocols	Mifare
USB 3.2 Gen 1 (3.1 Gen 1) ports quantity	0
Built-in processor	Yes
International Protection (IP) code	IP64
Frequency	13.56 MHz
Maximum read range	50 mm

Weight and Dimensions

Depth	121 mm
Width	86.5 mm
Height	14 mm
Weight	140 g
