HIKVISION DS-K1T341CMFW User Manual

The port number is obtained automacally.
User Name
By default, the user name is admin.
Password
Enter the device password.
Cauon
The password strength of the device can be automacally checked. We highly recommend
you change the password of your own choosing (using a minimum of 8 characters, including
at least three kinds of following categories: upper case leers, lower case leers, numbers,
and special characters) in order to increase the security of your product. And we recommend
you change your password regularly, especially in the high security system, changing the
password monthly or weekly can
beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
installer and/or end-user.
7.
Oponal: Check Synchronize Time to synchronize the device me with the PC running the client
aer adding the device to the client.
8.
Oponal: Check Import to Group to create a group by the device name.
Note
You can import all the channels of the device to the corresponding group by default.
9.
Click OK to add the device.
Add
Mulple Online Devices
You can add mulple online devices to the client soware.
Steps
1.
Enter the Device Management module.
2.
Click
on the right of Device Management and select Device.
3.
Click Online Device to show the online device area.
The searched online devices are displayed in the list.
4.
Select
mulple devices.
Note
For the inacve device, you need to create the password for it before you can add the device
properly. For detailed steps, refer to Acvaon .
5.
Click Add to open the device adding window.
6.
Enter the required informaon.
User Name
By default, the user name is admin.
DS-K1T341C Series Face Recognion Terminal User Manual
127

HIKVISION DS-K1T341CMFW Specifications

General

Type	Face recognition terminal
Face capacity	3000
Product color	Black, Grey
Cards capacity	3000 cards
Event capacity	150000
Wiegand interface	Yes
Fingerprint reader	-
Authentication type	Access chip/card, Face recognition
Fingerprint sensor type	Optical
Face recognition accuracy	99 %
Face recognition distance	1 - 2 m
Face recognition duration	0.2 s
Access chip/card reader type	Contactless
International Protection (IP) code	IP65
Display type	LCD
Screen shape	Flat
Display diagonal	4.3 \
Maximum resolution	272 x 480 pixels
Touchscreen technology	Capacitive
Sensor type	CMOS
Total megapixels	2 MP
Front camera type	Dual camera
Operating system installed	Linux
Ethernet LAN data rates	10, 100 Mbit/s
Input current	2 A
Input voltage	12 - 24 V
Power consumption (typical)	10 W
Operating temperature (T-T)	-30 - 60 °C
