HIKVISION DS-K1T341CMFW User Manual

Figure 9-2 Issue a Card by Local Mode
6.
Set other related parameters.
Card Enrollment
Staon
Select the model of the connected card enrollment staon.
Note
Currently, the supported card enrollment staon models include DS-K1F100-D8, DS-K1F100-
M, DS-K1F100-D8E, and DS-K1F180-D8E.
Card Type
This eld is only available when the model is DS-K1F100-D8E or DS-K1F180-D8E. Select the
card type as EM card or Mifare card according to the actual card type.
Buzzing
DS-K1T341C Series Face Recognion Terminal User Manual
138

HIKVISION DS-K1T341CMFW Specifications

General

Type	Face recognition terminal
Face capacity	3000
Product color	Black, Grey
Cards capacity	3000 cards
Event capacity	150000
Wiegand interface	Yes
Fingerprint reader	-
Authentication type	Access chip/card, Face recognition
Fingerprint sensor type	Optical
Face recognition accuracy	99 %
Face recognition distance	1 - 2 m
Face recognition duration	0.2 s
Access chip/card reader type	Contactless
International Protection (IP) code	IP65
Display type	LCD
Screen shape	Flat
Display diagonal	4.3 \
Maximum resolution	272 x 480 pixels
Touchscreen technology	Capacitive
Sensor type	CMOS
Total megapixels	2 MP
Front camera type	Dual camera
Operating system installed	Linux
Ethernet LAN data rates	10, 100 Mbit/s
Input current	2 A
Input voltage	12 - 24 V
Power consumption (typical)	10 W
Operating temperature (T-T)	-30 - 60 °C
