The maximum transmission unit (MTU) of the network interface.
6.
Click Save.
Set Network Parameters
Aer adding the access control device, you can set the device log uploading mode, and create ISUP
account via wired network.
Set Log Uploading Mode
You can set the mode for the device to upload logs via ISUP protocol.
Steps
1.
Enter the Access Control module.
2.
On the
navigaon bar on the le, enter Advanced Funcon → More Parameters .
3.
Select an access control device in the device list and enter Network → Uploading Mode .
4.
Select the center group from the drop-down list.
5.
Check Enable to enable to set the uploading mode.
6.
Select the uploading mode from the drop-down list.
-
Enable N1 or G1 for the main channel.
-
Select Close to disable the main channel.
7.
Click Save.
Create ISUP Account in Wired
Communicaon Mode
You can set the account for ISUP protocol in wired communicaon mode. Then you can add
devices via ISUP protocol.
Steps
Note
This funcon should be supported by the device.
1.
Enter the Access Control module.
2.
On the navigaon bar on the le, enter Advanced Funcon → More Parameters .
3.
Select an access control device in the device list and enter Network → Network Center .
4.
Select the center group from the drop-down list.
5.
Select the Address Type as IP Address or Domain Name.
6.
Enter IP address or domain name according to the address type.
7.
Enter the port number for the protocol.
DS-K1T341C Series Face Recognion Terminal User Manual
173

HIKVISION DS-K1T341CMFW Specifications

General

Type	Face recognition terminal
Face capacity	3000
Product color	Black, Grey
Cards capacity	3000 cards
Event capacity	150000
Wiegand interface	Yes
Fingerprint reader	-
Authentication type	Access chip/card, Face recognition
Fingerprint sensor type	Optical
Face recognition accuracy	99 %
Face recognition distance	1 - 2 m
Face recognition duration	0.2 s
Access chip/card reader type	Contactless
International Protection (IP) code	IP65
Display type	LCD
Screen shape	Flat
Display diagonal	4.3 \
Maximum resolution	272 x 480 pixels
Touchscreen technology	Capacitive
Sensor type	CMOS
Total megapixels	2 MP
Front camera type	Dual camera
Operating system installed	Linux
Ethernet LAN data rates	10, 100 Mbit/s
Input current	2 A
Input voltage	12 - 24 V
Power consumption (typical)	10 W
Operating temperature (T-T)	-30 - 60 °C
