Note
If you select Access Controller: If connect the device to a terminal via the RS-485 interface, set
the RS-485 address as 2. If you connect the device to a controller, set the RS-485 address
according to the door No.
Baud Rate
The baud rate when the devices are communicang via the RS-485 protocol.
Data Bit
The data bit when the devices are communicang via the RS-485 protocol.
Stop Bit
The stop bit when the devices are communicang via the RS-485 protocol.
Parity/Flow Ctrl/Communicaon Mode
Enabled by default.
Set Wiegand Parameters
You can set the Wiegand transmission direcon.
Steps
1.
Tap Conguraon → Access Control → Wiegand Sengs .
Figure 8-15 Wiegand Page
2.
Enable Wiegand to enable the Wiegand funcon.
3.
Set a transmission direcon.
Input
The device can connect a Wiegand card reader.
Output
