HIKVISION DS-K1T342MX User Manual

Figure 3-1 Install Gang Box
2.
Secure the mounng plate on the gang box with two supplied screws (SC-KA4X22).
Figure 3-2 Install Mounng Plate
3.
Route the cable through the cable hole, wire the cables and insert the cables in the gang box.
DS-K1T342 Series Face Recognion Terminal User Manual
6

HIKVISION DS-K1T342MX Specifications

General

Brand	HIKVISION
Model	DS-K1T342MX
Category	Touch terminals
Language	English
