HIKVISION DS-K1T342MX User Manual

Figure 3-19 Fix Mounng Plate
3.
Route the cables through the cable hole on the turnsle.
4.
Fix the face recognion terminal into the mounng plate with 1 SC-KM3×6-H2-SUS screw.
Figure 3-20 Fix Mounng Plate
5.
Aer installaon, for the proper use of the device (outdoor use), sck the protecon lm (parts
of models supplied) on the screen.
DS-K1T342 Series Face Recognion Terminal User Manual
19
