HIKVISION DS-K2602 - Chapter 4 Card Reader Installation; External Terminal Connections

DS-K2600 Series Access Controller
19
No.
DS-K2604
B12
D3-
B13
E-Lock 4
D4+
Door 4 Door Relay Input (Dry Contact)
B14
D4-
B15
Door
Magnetics
Input
S1
Door 1 Magnetic Detector Input
B16
GND
Signal Grounding
B17
S2
Door 2 Magnetic Detector Input
B18
S3
Door 3 Magnetic Detector Input
B19
GND
Signal Grounding
B20
S4
Door 4 Magnetic Detector Input
B21
Door Button
B1
Door 1 Door Button Input
B22
GND
Signal Grounding
B23
B2
Door 2 Door Button Input
B24
B3
Door 3 Door Button Input
B25
GND
Signal Grounding
B26
B4
Door 4 Door Button Input
C1
Power
+12V
DC12V Cathode
C2
GND
Grounding
C3
Battery
BAT+
DC12V Battery Cathode
C4
BAT-
DC12V Battery Anode
C5
Card Reader
RS485
RS
485A+
Card Reader RS485A+
C6
RS 485A-
Card Reader RS485A-
C7
GND
Grounding
