HIKVISION DS-K2602 - Weigand Card Reader Connection

DS-K2600 Series Access Controller
20
No.
DS-K2604
C8
RS 485B+
Card Reader RS485B+
C9
RS 485B-
Card Reader RS485B-
C10
GND
Grounding
C11
Access
Controller
RS485
RS 485C+
Uplink RS485+Communication
C12
RS 485C-
Uplink RS485-Communication
C13
GND
Grounding
C14
RS
485D+
Reserved
C15
RS 485D-
C16
GND
C17
Alarm
Output
NO/NC1
Alarm Relay 1 Output (Dry Contact)
C18
COM1
C19
NO/NC2
Alarm Relay 2 Output (Dry Contact)
C20
COM2
C21
NO/NC3
Alarm Relay 3 Output (Dry Contact)
C22
COM3
C23
NO/NC4
Alarm Relay 4 Output (Dry Contact)
C24
COM4
D1
Event Input
C8
Event Alarm Input 8
D2
GND
Grounding
D3
C7
Event Alarm Input 7
D4
C6
Event Alarm Input 6
D5
GND
Grounding
