HIKVISION DS-K2604T User Manual

DS-K2600 Series Access Controller
11
Table 3-2 DS-K2602 Terminal Description
No.
DS-K2602
A1
Power for
E-Lock
GND
Grounding
A2
+12V
Power Output of the Lock
A3
Power for
Card Reader
GND
Grounding
A4
+12V
Power Output of the Head Read
A5
Wiegand Card
Reader 4
GND
Grounding
A6
W0
Wiegand Head Read Data Input Data0
A7
W1
Wiegand Head Read Data Input Data1
A8
BZ
Card Reader Buzzer Control Output
A9
ERR
Indicator of Card Reader Control Output
(Invalid Card Output)
A10
OK
Indicator of Card Reader Control Output (Valid
Card Output)
A11
Wiegand Card
Reader 3
GND
Grounding
A12
W0
Wiegand Head Read Data Input Data0
A13
W1
Wiegand Head Read Data Input Data1
A14
BZ
Card Reader Buzzer Control Output
A15
ERR
Indicator of Card Reader Control Output
(Invalid Card Output)
A16
OK
Indicator of Card Reader Control Output (Valid
Card Output)
A17
Wiegand Card
Reader 2
GND
Grounding
A18
W0
Wiegand Head Read Data Input Data0
A19
W1
Wiegand Head Read Data Input Data1
A20
BZ
Card Reader Buzzer Control Output
A21
ERR
Indicator of Card Reader Control Output
(Invalid Card Output)
A22
OK
Indicator of Card Reader Control Output (Valid
Card Output)
A23
Wiegand Card
Reader 1
GND
Grounding
A24
W0
Wiegand Head Read Data Input Data0

HIKVISION DS-K2604T Specifications

General

Material	Metal
Product type	Access controller
Certification	CE, FCC, CB
Product color	Gray
Brand compatibility	Hikvision
Operating temperature (T-T)	-20 - 65 °C

Weight and Dimensions

Depth	373 mm
Width	345 mm
Height	98 mm
