HIKVISION DS-K2604T User Manual

DS-K2600 Series Access Controller
12
No.
DS-K2602
A25
W1
Wiegand Head Read Data Input Data1
A26
BZ
Card Reader Buzzer Control Output
A27
ERR
Indicator of Card Reader Control Output
(Invalid Card Output)
A28
OK
Indicator of Card Reader Control Output (Valid
Card Output)
B1
Arming Region
Z1
Arming Region Access Terminal 1
B2
GND
Grounding
B3
Z2
Arming Region Access Terminal 2
B4
Z3
Arming Region Access Terminal 3
B5
GND
Grounding
B6
Z4
Arming Region Access Terminal 4
B7
E-Lock1
D1+
Door 1 Door Relay Input (Dry Contact)
B8
D1-
B9
E-Lock2
D2+
Door 2 Door Relay Input (Dry Contact)
B10
D2-
B11
Door
Magnetics
Detector
S1
Door 1 Magnetic Detector Input
B12
GND
Signal Grounding
B13
S2
Door 2 Magnetic Detector Input
B14
Door Button
B1
Door 1 Door Button Input
B15
GND
Signal Grounding
B16
B2
Door 2 Door Button Input
C1
Power
+12V
DC12V Cathode
C2
GND
Grounding
C3
Battery
BAT+
DC12V Battery Cathode
C4
BAT-
DC12V Battery Anode
C5
Card Reader
485 Interface
RS
485A+
Card Reader RS485+ Access
C6
RS
485A-
Card Reader RS485- Access
C7
GND
Grounding
C8
RS
Card Reader RS485+

HIKVISION DS-K2604T Specifications

General

Material	Metal
Product type	Access controller
Certification	CE, FCC, CB
Product color	Gray
Brand compatibility	Hikvision
Operating temperature (T-T)	-20 - 65 °C

Weight and Dimensions

Depth	373 mm
Width	345 mm
Height	98 mm
