HIKVISION DS-K3G4402 Series User Manual

Tri-pod Turnstile • User Manual
9
The anti-reversal device is used to prevent rotation of the rotary unit in the opposite
direction to that of the initial rotation. This means that once the tripod has been moved in one
direction, the device will prevent a reverse movement in the opposite direction.
7) Tripod
The tripod, which is fitted by three screws, is composed of three lock arms, three arm detents
and a drop arm. The arms are positioned at 120° intervals, so that when the tripod comes to rest,
one of the arms will be in the barrier position.
The electric control system consists of access control device, control board, direction
indicator, position sensor, solenoid, tamper, power supply.
NO
Name
Function
1
Access control
device
IC/ID card access control, fingerprint, face recognition,
code reader, access control device send delay signal to the
turnstile board door signal（It is available according to
actual use）
2
Control board
The control center of the system, when receiving the
access control device delay signal, it control solenoid
open ,the direction indicator light turns green, The arm can
be pushed to 120 degree ,the solenoid will lock
immediately when receiving closing signal from core
position sensor.
3
Indicator
Display the current channel status
4
Position sensor
Detects and controls the opening and closing position of
the gate
5
Square solenoid
Control shatf close or open
6
Circular solenoid
Falling and upper arm
7
Damper
Makes the shaft run smoothly(match)
8
Power Supply
power supply to control board
