HIKVISION DS-K3G4402 Series User Manual

Tri-pod Turnstile • User Manual
10
1.4.2Work principle
Turn on power and lift arm manually,the drop device lock.
The LED indicator light on the surface, if the control PCB board receive open signal, turnstile
will have green arrows in the direction.The Square solenoid open ,Push arm and go through,The
Square solenoid open arm turn 120 degree.This process position sensor be induced ,send closing
signal to board,The Square solenoid lock immediately.
Turn off power the arm will fall down.
Chapter 2 Equipment Installations
2.1 Installation notes
 If it tests well before installation, then fixed it; before you install and maintain it, please cut off
the power;
 The product must be earthed, and an earth leakage breaker is necessary on the power supply;
 The depth of buried PVC tube should be greater than 60mm, and the exposed height above
the ground should be greater than 50mm. The exit mouth should be bending back to avoid
water dipping inside the tube;
 Don’t change the inside wire of the turnstile casually;
 In installation, please make each door of the lane are in alignment;
 Tighten the mounting screws of the arm
 if you use the turnstile outdoor, it need t need to add a canopy to protect the turnstile from
sun and rain;
2.2 Equipment Installation
1) Tool preparations
1
A set of hexagon spanner
5
Screw driver and other common wiring
tool
2
Cross screwdriver 6mm
6
Millimeter
3
Open spanner 17-19mm
7
M10x100 Expansion screws 8pcs
4
Impact drill D14
8
Cable Tester
