HIKVISION DS-K3H4420-120 User Manual

Full high turnstile • User Manual
8
Function Features
 Damper buffer device
 Standard signal input port, can be connected with most of the access control board,
fingerprint device and scanner other equipment;
 The turnstile has automatic reset function, if people swipe the authorized card, but don’t pass
through within the settled time, it need to swipe card again for entry;
 Card-reading Recording function
 Automatic opening after emergency fire signal input
 Anti following : prevent illegal passing
 High light LED indicator , displaying passing status.
 Normal open can be also controlled via external button or manual key unlock
 Gate will automatically open when power failure(connect 24V battry)
Tchnical parameter
Basic Parameters
1
Input voltage
AC 220V 50HZ
2
Work voltage
DC 24V /50W
3
Housing Material
304 Stainless Steel
4
Arm rotation angle
90/120 degree
5
Lane Width
≦650mm
6
Opening response time
≦0.2s
7
Open Signal
Passive signals (relay signals, dry
contact signals,)
8
Communication
RS485
9
Pass rate
25-30 person/min

HIKVISION DS-K3H4420-120 Specifications

General

Brand	HIKVISION
Model	DS-K3H4420-120
Category	Turnstiles
Language	English
