Note

●

The dimension of two-module mounng frame (W × H × D) is:

321 mm × 107 mm × 33 mm.

●

The dimensions above are for reference only. The actual size

can be slightly dierent from the theorecal dimension.

Steps

1. Paste the installaon scker 1 onto the wall. Make sure the

scker is placed horizontally via measuring with the gradienter.

2. Drill 4 holes according to the screw holes on the

scker.The

suggested size of hole is 6 (diameter) × 25 (depth) mm. The

suggested length of cables le outside is 270 mm.

Figure 4-17 Drill Screw Holes

Remove the scker and insert the expansion sleeves into the

screw holes.

4. Fix the

mounng frame onto the wall with 4 expansion bolts.

Figure 4-18 Fix the Mounng Frame

Note

The mounng frame should be placed exactly as shown below

for this step. The tamper plate should be at the low right of the

rst grid.
